12471638
$129.00
| Series: | 1344 (3R) |
| U-Joint Lock Up: | 2.556 Inch |
| Bearing Cap Diameter: | 1.125 Inch |
| Type: | Inside Snap Ring |
| Vehicle Make: | GM |
| Spline Count: | 32 |
| Spline Length: | 3.350 Inch (85.10 mm) |
| Spline Diameter: | 1.375 Inch |
| Nominal Tube Diameter: | 2.75 Inch X 0.059 Inch |
| Overall Length: (Centerline to End) |
7.83 Inch (199.00 mm) |
| Shaft length: | 3.74 Inch (95.00 mm) |
| Shaft Width: | 1.75 Inch (44.50 mm) |
Fits the following :
Cadillac Escalade EXT 2002-2012
Cadillac Escalade 2002-2013
Chevrolet Tahoe 2001-2014
Chevrolet Suburban 2500 2001-2013
Chevrolet Suburban 1500 2001-2014
Chevrolet Silverado 3500 2001-2014
Chevrolet Silverado 2500 HD 2001-2014
Chevrolet Silverado 2500 2001-2014
Chevrolet Silverado 1500 HD 2001-
Chevrolet Silverado 1500 2001-2018
Chevrolet Express Van 1500 2012-2014
Chevrolet Express Van 2500 2012-2014
Chevrolet Express Van 3500 2012-2014
GMC Yukon XL 2500 2001-2013
GMC Yukon XL 1500 2001-2013
GMC Yukon 1500 2001-2019
GMC Sierra 3500 2001-2014
GMC Sierra 2500 HD 2001-2014
GMC Sierra 2500 2001-2014
GMC Sierra 1500 HD 2001-2013
GMC Sierra 1500 2001-2019
GMC Savana Van 1500 2012-2014
GMC Savana Van 2500 2012-2014
GMC Savana Van 3500 2012-2014
Hummer H2 2003-2009
Use Boot: N2112504
Applications NP246, NP263, NP261 and BW4473 transfer cases
Additional Information
Same as :
40006885,
N3R-82-1181,
12471638,
697-518,
74086885,
26060595,
3R82-321,
Forging # 40006884,
| Weight | 5 lbs |
|---|---|
| Dimensions | 12 × 5 × 5 in |
